Product Details:
|
| Origin:: | Hebei China | Processing Type: | Forging |
|---|---|---|---|
| Applicable Industries: | Energy & Mining, Deepwater Drilling | Type: | Drill Pipe |
| Advantage: | Reliable Material And Long Service Life | Section Shape: | Round/square |
| Standard: | API, API 5CT | Material: | Alloy Steel |
| Highlight: | 4.5 inch water well drill stem,ingersoll rand water well drill stem,114mm ingersoll rand drill pipe |
||
4.5 inch G105 Ingersoll Rand drill pipe 114mm water well drill pipe T4 API drill pipe
Precautions:
1. Before connecting the new drill pipe, thread oil should be applied
2. Up and down at least 3 times before drilling
3. Hard bending and plastic coating can be processed according to the special requirements of customers.
| Processing type | Forging |
| Machine type | Drilling Equipment |
| Type | Drill Pipe |
| Advantage | Reliable Material And Long Service Life |
| OD A | 4 1/2" |
| Wall B | 0.337" |
| Length L | 25' |
| Weight 1bs | 415 |
| Dist From ShoulderC | 3" |
| Across Flat E | 3 1/2" |
| Recess DIA F | 3 1/2" |
| Recess Location H | 3 1/2" |
| Recess Length K | 5" |
| Across Hex M | 3 3/8" |
| Connection | 4" |
| P/M | 3 1/2 Reg |
Features
1. The pipe joint is made of upsetting forging, the hardness is increased, and the wear resistance is better.
2. Pipe chemistry with our quenching and tempering heat treatment
3. Couplings and pipes are friction welded, and heat treated end pieces for optimum durability.
4. High hardness and wear-resistant composite alloy steel provided by top national special steel manufacturers
Drill pipe usage notes
1. New drill pipe should be pasted thread oil before connection
2. Make up and break at least 3 times before drilling
3. Hard bending and plastic coating can be processed according to costumer special requirement.
