OD 200mm Fluted reamer is used for HDD reaming high steal grade

Large Image : OD 200mm Fluted reamer is used for HDD reaming high steal grade

Product Details:

Place of Origin:	Hebei China
Brand Name:	BaiWei
Certification:	ISO9001
Model Number:	200mm

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiable
Packaging Details:	According to customer needs
Delivery Time:	5-15 working days, which will be adjusted according to different products and inventory
Payment Terms:	T/T
Supply Ability:	50 sets/month

Contact Now

OD 200mm Fluted reamer is used for HDD reaming high steal grade

Description

Place Of Origin:	HeBei, China	Product Name:	HDD Fluted Reamer
Color:	Required	Material:	High Manganese Steel
Type:	HDD Back Reamer, Barrel, Fluted, Cutting, Fly Cutter	Usage:	HDD Projects
Size:	As You Requirement All Size	Application:	Well Drilling, Horizontal Directional Drilling
Machine Type:	Drilling Tool	Processing Type:	Casting
Highlight:	2000mm hdd hole opener drilling , O.D.200mm hdd hole opener drilling , 2000mm pdc reamer

OD 200mm Fluted reamer is used for HDD reaming high steal grade

Product Description

Size: 200-2000mm

Suitable for soft soil.

Connection with drill rod: Direct connection with drill rod

Octagonal connection

Connection with laid pipe: Within or without swivel

Barrel Reammer parameter list
serial number	1	2			3			4
serial number	specification D	dabber B	length C	length E	dabber B	length C	length E	dabber B	length C	length E
1	Φ200	Φ60	50	280	Φ68	50	330	Φ76	60	400
2	Φ250	Φ60	50	280	Φ68	50	330	Φ76	60	400
3	Φ300	Φ60	50	280	Φ68	50	330	Φ76	60	400
4	Φ350	Φ60	50	280	Φ68	50	330	Φ76	60	400
5	Φ400	Φ60	50	280	Φ68	50	330	Φ76	60	400
6	Φ500	Φ60	50	280	Φ68	50	330	Φ76	60	400
7	Φ600	Φ60	50	280	Φ68	50	330	Φ76	60	400
8	Φ700	Φ60	50	280	Φ68	50	330	Φ76	60	400
9	Φ800	Φ60	50	280	Φ68	50	330	Φ76	60	400
10	Φ900	Φ60	50	280	Φ68	50	330	Φ76	60	400
11	Φ1000							Φ76	60	400
12	Φ1100							Φ76	60	400
13	Φ1200							Φ76	60	400
14	Φ1300
15	Φ1400
16	Φ1500
17	Φ1600
18	Buckle type A	Φ50 drill pipe buckles are recommended			Φ60 drill pipe buckles are recommended			Φ73 drill pipe buckles are recommended

serial number	1	5			6			7
serial number	specification D	dabber B	length C	length E	dabber B	length C	length E	dabber B	length C	length E
1	Φ159	Φ89	80	450	Φ95	80	450	Φ102	110	450
2	Φ219	Φ89	80	450	Φ95	80	450	Φ102	110	450
	Φ273	Φ89	80	450	Φ95	80	450	Φ102	110	450
	Φ325	Φ89	80	450	Φ95	80	450	Φ102	110	450
5	Φ425	Φ89	80	450	Φ95	80	450	Φ102	110	500
6	Φ529	Φ89	80	450	Φ95	80	450	Φ102	110	500
7	Φ630	Φ89	80	450	Φ95	80	450	Φ102	110	500
8	Φ670	Φ89	80	450	Φ95	80	450	Φ102	110	500
9	Φ770	Φ89	80	450	Φ95	80	450	Φ102	110	500
10	Φ870	Φ89	80	450	Φ95	80	450	Φ102	110	500
11	Φ1000	Φ89	80	450	Φ95	80	450	Φ102	110	500
12	Φ1100	Φ89	80	450	Φ95	80	450	Φ102	110	500
13	Φ1200	Φ89	80	450	Φ95	80	450	Φ102	110	500
14	Φ1300	Φ89	80	450	Φ95	80	450	Φ102	110	500
15	Φ1400							Φ102	110	500
16	Φ1500							Φ102	110	500
17	Φ1600							Φ102	110	500
18	Buckle type A	Φ73/76drill pipe buckles are recomended			Φ83 drill pipe buckles are recommended			Φ89 drill pipe buckles are recompended

serial number	1	8			9			10
serial number	specification D	dabber B	length C	length E	dabber B	length C	length E	dabber B	length C	length E
1	Φ159
2	Φ219	108	110	450
3	Φ273	Φ108	110	450
4	Φ325	108	110	450	Φ121	110	550
5	Φ425	108	110	500	Φ121	110	550	Φ127	110	550
6	Φ529	Φ108	110	500	Φ121	110	550	Φ127	110	550
7	Φ630	Φ108	110	500	121	110	550	Φ127	110	550
8	Φ670	Φ108	110	500	Φ121	110	550	Φ127	110	550
9	Φ770	Φ108	110	500	Φ121	110	550	127	110	550
10	Φ870	Φ108	110	500	Φ121	110	600	Φ127	110	600
11	Φ1000	108	110	500	Φ121	110	600	Φ127	110	600
12	Φ1100	Φ108	110	500	Φ121	110	600	Φ127	110	600
13	Φ1200	Φ108	110	500	Φ121	110	600	Φ127	110	600
14	Φ1300	Φ108	110	500	Φ121	110	600	Φ127	110	600
15	Φ1400	108	110	500	Φ121	110	600	Φ127	110	600
16	Φ1500	108	110	500	Φ121	110	600	Φ127	110	600
17	Φ1600	Φ108	110	500	Φ121	110	600	Φ127	110	600
18	Buckle type A	Φ89 drill pipe buckles are recommended			Φ102/Φ114drill pipe buckles are recommended			Φ114 drill pipe buckles are recommended

serial number	1	11			12
serial number	specification D	dabber B	length C	length E	dabber B	length C	length E
1	Φ159
2	Φ219
3	Φ273
4	Φ325
5	Φ425	Φ168	180	650	Φ194	200	700
6	Φ529	Φ168	180	650	Φ194	200	700
7	Φ630	Φ168	180	650	Φ194	200	700
8	Φ670	Φ168	180	650	Φ194	200	700
9	Φ770	Φ168	180	650	Φ194	200	700
10	Φ870	Φ168	180	650	Φ194	200	700
11	Φ1000	Φ168	180	650	Φ194	200	700
12	Φ1100	Φ168	180	650	Φ194	200	700
13	Φ1200	Φ168	180	650	Φ194	200	700
14	Φ1300	Φ168	180	650	Φ194	200	700
15	Φ1400	Φ168	180	650	Φ194	200	700
16	Φ1500	Φ168	180	650	Φ194	200	700
17	Φ1600	Φ168	180	650	Φ194	200	700
18	Buckle type A	Φ114/Φ127 drill pipe buckles are recommended			140 drill pipe buckles are reconended

Product Advantages

Optimized structure & ingenious design, faster driling, speed

Premium roller cone cutters (optional for different crossing)

Enhanced TCl protection on heel of cones and ammback

Bunched tungsten carbide protection on body

Bunched tungsten carbide protection on stabilizer

Heavy duty dril collar from petroleum industry

OD 200mm Fluted reamer is used for HDD reaming high steal grade 0

Our Services

1. Drill pipe strictly in accordance with ISO9001 standard

2. If you find a quality problem within one month of the package being returned.

3. All obligations and responsibilities are strictly performed in accordance with the contract

4. 24-hour online customer service, feel free to contact us.

About us

Langfang Budweiser Drilling Co., Ltd. is located in the center of Beijing, Tianjin and Hebei-Yongqing Industrial Zone. Langfang, Hebei.

Our company is a drilling tool manufacturing enterprise integrating design, geology, wellbore, double-wall, petroleum, auger and other special drill pipes. And non-excavation special drilling tools, such as pilot bits, rotors, reamers, fuel economizers, pneumatic tampers, and pipe blasting machines.

We specially invited the well-known domestic expert Mr. Zhou Shengfeng as the general manager, he is a technical consultant engaged in HDD drilling tools and processing technology. A strong research team has laid the foundation for product quality, new product development and after-sales service.
