Dependable Pneumatic Hammer For Pipe Ramming

Large Image : Dependable Pneumatic Hammer For Pipe Ramming

Product Details:

Place of Origin:	China
Brand Name:	Longway
Certification:	ISO9001
Model Number:	BH200

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$18429-$19600
Packaging Details:	carton
Delivery Time:	5-8 days
Payment Terms:	T/T
Supply Ability:	10 sets/Month

Contact Now

Dependable Pneumatic Hammer For Pipe Ramming

Description

Type:	BH260	Outer Diameter Of The Main Unit:	260/265mm
Length Of The Main Unit:	1390mm	Weight Of The Main Unit:	320kg
Air Consumption:	3～8m³/min	Air Pressure:	0.4～0.7MPa
Instantaneous Maximum Impact Force:	2600kN	Applicable Pipe Laying Diameter:	159～426mm
Standard Configuration Pipe Laying Diameter:	273、325、426mm

Product Description

In the field of trenchless laying of underground pipelines, pneumatic tamping pipeline laying technology is accepted by most construction units due to its simple structure, high precision, high speed, and low cost. It has become a preferred economical and fast construction method, and is widely used in the rescue of horizontal directional drilling projects and the construction of scaffolding.

Dependable Pneumatic Hammer For Pipe Ramming 1

Specification of BM Series Pneumatic Ramming Hammer
Model	Host outer diameter (mm)	Host length (mm)	Host weight (kg)	Air consumption (m3/min)	Air pressure (MPa)	Instant maximum impact (kN)	Applicable pipe laying diameter (mm)	Standard pipe laying diameter (mm)	Extended configuration pipe diameter series (mm)	Main unit and standard accessories (including oil injector, two air ducts, three types of pipe ramming heads, earth extraction device, cone sleeve, etc.)
BH190S	186/194	1320	160	2-6	0.4-0.7	1500	89-273	108,159,219	Φ89,Φ108,Φ159,Φ219,Φ273,Φ325,Φ377,Φ426,Φ529,Φ630,Φ720,Φ820,Φ920,Φ1020,Φ1100,Φ1200,Φ1500,Φ2000	70,000
BH260	260/265	1390	320	3-8	0.4-0.7	2600	159-426	273,325,426		115,000
BH300	290/300	2100	750	4-11	0.4-0.7	4500	219-630	325,426,529		160,000
BH350	350/365	2400	1200	6-17	0.4-0.7	6000	273-820	426,529,630		242,000
BH420	415/425	2800	1950	9-21	0.4-0.7	8000	325-1200	426,529,630		297,000
BH510	510/520	3200	3400	12-28	0.4-0.7	12000	426~1500	630,720,820		495,000
BH610	610/620	3400	5100	20-40	0.4-0.7	20000	529-1800	8,209,201,020		715,000
BH650	620/650	3600	5500	20-50	0.4-0.9	25000	529~2200	8,209,201,020		825,000
BH700	700/710	3680	7100	28-60	0.4-0.7	28000	630-2500	102,011,201,220		1,050,000
BH750	700/740	3870	8000	28～70	0.4～0.9	32000	630～2800	1020,1120,1220		1,320,000
BH850	800/850	4640	12000	35～96	0.4～0.9	45000	720～3200	1220,1320,1420	(Selected by the user)	2,000,000

Product Description

Anvil after clamping
The back anvil is the mark of BAIWEI perforation tool design. The clamping load provided by this function is 200% higher than that of competing products, making it the safest component on the market.

Forward wear ring
The one-piece striker contains a set of wear rings that eliminate metal-to-metal contact, thereby providing a sustained level of performance.

Push chuck
The BAIWEI tamper tool can be set into a conical locking chuck, thereby reducing the time for setting up and disassembly. The chuck can be fully engaged with the steel housing by 6 inches (152 mm), thereby firmly locking the tip of the knife on the housing, eliminating the need for a support frame, and reducing the opening of the sleeve, thereby saving working time.
