Product Details:
|
| Standard: | API | Guarantee Time: | Usage Time ≥ 100 Hours |
|---|---|---|---|
| Thread Type: | API Standard | Tool Joint OD: | More Drill Pipe Size |
| Packing Specification: | 10-60 Pcs | Product Name: | Double Wall Drill Pipe |
| Colored: | Black，blue | Weight: | 185kg/pc,100kg/pc |
| Highlight: | 185kg/pc Double Wall Drill Pipe,API Standard Dual-Wall Drilling Pipe,API Standard Double Layer Drill Pipe |
||
The Double Wall Drill Pipe is compatible with API Standard thread types, ensuring that it can be easily connected with other components of the drilling system. This feature makes it a versatile and reliable choice for drilling operations across different industries.
The Double Wall Drill Pipe is available in two different weight options, 185kg/pc and 100kg/pc, allowing drilling operators to choose the weight that suits their specific needs. The Double Wall Drilling Pipe comes with a guarantee time of usage time ≥ 100 hours, providing drilling operators with the confidence they need to complete their drilling operations successfully.
When drilling in challenging conditions, the Double Wall Drill Pipe is an essential component for maintaining the integrity of the drilling system. Its unique design ensures that drilling fluid can circulate efficiently and effectively, providing a smooth drilling experience and reducing the risk of damage to the system.
Overall, the Double Wall Drill Pipe is a reliable and durable solution for drilling operations that require a Reverse circulation Piping System. Its compatibility with API Standard thread types, carbon steel material, and 8.56mm wall thickness make it a versatile and sturdy choice for drilling operators across different industries.
| Product Attribute | Value |
|---|---|
| Product Name | Double Wall Drilling Pipe |
| Size | All Models |
| Weight | 185kg/pc, 100kg/pc |
| Steel Grade | R780, S135, E75 |
| Material | Carbon Steel |
| Outer Diameter | 73, 76, 89, 102, 114, 127, 168, 219mm |
| Guarantee Time | Usage Time ≥ 100 Hours |
| Packing Specification | 10-60 Pcs |
| Delivery Time | 25 Days |
| Colored | Black, Blue |
| Wall Thickness | 8.56mm |
The International standard drill pipe is used in various fields such as rock drilling, mining exploration, geological exploration, engineering, and oil exploration. The drill pipe comes in many diameter ranges for different applications.
Diameter range: 27mm-43mm
Inner diameter range: 18mm-31.75mm
Usage: Widely used in rock drilling and mining exploration
Diameter range: 36mm-60mm
Inner diameter range: 22mm-36mm
Usage: In the fields of geological exploration, basic engineering, and water conservancy engineering, etc
Diameter range: 47mm-89mm
Inner diameter range: 32mm-56mm
Usage: In the fields of deep hole geotechnical exploration and hydraulic drilling, etc
Diameter range: 76mm-146mm
Inner diameter range: 46mm-101mm
Usage: In geological drilling and oil exploration
Diameter: 42mm
Inner diameter: 28mm
Purpose: Suitable for different types of geological drilling and exploration of engineering structures
Diameter: 50mm
Inner diameter: 34mm
Usage: Suitable for different fields such as geotechnical exploration, foundation construction, etc
Diameter: 60mm
Inner diameter: 40mm
Usage: Suitable for drilling operations in deeper boreholes such as highway tunnels and subway construction
5-inch (127mm) drill pipe: outer diameter 127mm, inner diameter 108mm
7-inch (178mm) drill stem: outer diameter 178mm, inner diameter 71.40mm
8-inch (203mm) drill stem: outer diameter 203mm, inner diameter 71.40mm
In addition, there are various specifications for the length of drill pipes, such as 0.5m, 0.8m, 1.0m, 1.5m, as well as common lengths of 6m, 9m, or 12m.
Product Packaging:
The Double Wall Drill Pipe product will be securely packaged in wooden crates, with each pipe being wrapped in protective material to prevent damage during transport.
Shipping:
The Double Wall Drill Pipe product will be shipped via a reputable freight service, with options for both sea and air transport. Customers will be provided with tracking information so they can monitor the delivery of their order.
Q: What is the brand name of the product?
A: The brand name of the product is LONGWAY.
Q: What is the model number of the product?
A: The model number of the product is Double Wall Drill Pipe.
Q: Where is the product manufactured?
A: The product is manufactured in Langfang city, Hebei.
Q: What certifications does this product have?
A: This product has ISO9001 and API certifications.
Q: What is the minimum order quantity for this product?
A: The minimum order quantity for this product is 20 pcs.
Q: What is the price of the product?
A: The price of the product is negotiable and can be discussed based on the order quantity and other factors.
Q: What are the packaging details for this product?
A: The packaging for this product will be customized according to the specifications and standards required by the customer.
Q: How long does it take for the product to be delivered?
A: The product will be delivered within 5-10 working days after the order is confirmed.
Q: What are the payment terms for this product?
A: The payment terms for this product are T/T and L/C.
Q: What is the supply ability for this product?
A: The supply ability for this product is 50 pcs per day.
