4.5inch 20FT Length well drill pipe high-strength drill pipe

Large Image : 4.5inch 20FT Length well drill pipe high-strength drill pipe

Product Details:

Place of Origin:	Hebei China
Brand Name:	BaiWei
Certification:	ISO9001
Model Number:	4.5"

Payment & Shipping Terms:

Minimum Order Quantity:	30pcs
Price:	Negotiable
Packaging Details:	According to customer needs
Delivery Time:	20-30 working days, which will be adjusted according to different products and inventory
Payment Terms:	T/T
Supply Ability:	500 Pcs per month

Contact Now

4.5inch 20FT Length well drill pipe high-strength drill pipe

Description

Type:	DTH Pipes	Machine Type:	Drilling Equipment
Material:	High Manganese Steel	Processing Type:	Forging
Use:	Well Drilling	Application:	Well Drilling,DTH Drilling, Coal Drilling, Quarrying
Pressure:	High Pressure	Diameter:	114mm OD
Length:	15FT/20FT/25FT/30FT	Color:	Request
Advantage:	High Performance	Usage:	Well Drilling
Highlight:	20FT Welding Oilfield Pipe , Welding Oilfield Pipe 12.5inch , 20FT Welding Rod For Drill Pipe

4.5inch 20FT Length well drill pipe high-strength drill pipe

Product Description

Drill pipe is the abbreviation of downhole drill pipe, which is a kind of flat drill pipe. It is mainly used for rotary percussion drills containing gas and liquid. Its main components include tube (rod) body and joints. Our down-the-hole drill pipes are manufactured according to API standards. And according to specific requirements, we also provide drill pipes of different specifications such as IF and REG.The quality is guaranteed.

1. Big rigidity
2. Good sealing capacity
3. Flat outer structure
4. Low torque and resistance when rotating

OD A	Wall B	Length L	Weight lbs	ID Pin C	Across Flat D	Flat Length E	Dist From Shoulder F	Flat Length G	Across Flat H	Connection
3.5"	.315"	20'	245	1.75"	2.75"	12.5"	3.25"	2.25"	3.25"	2 3/8IF
4.5"	.337"	20'	345	1.75"	3"	12.5"	3.25"	2.375"	4"	3 1/2 Reg
4 1/2"	.337"	20'	345	2 1/8"	3"	12 1/2"	3 1/4"	2 3/8"	4"	2 7/8 IF
4 1/2"	.337"	25'	430	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.337"	25'	430	2 1/8"	3"	12 1/2"	3 1/4"	2 3/8"	4"	2 7/8 IF
4 1/2"	.337"	30'	510	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.500"	25'	510	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.500"	30'	615	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.750"	25'	805	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.500"	25'	695	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.500"	30'	775	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.750"	30'	1100	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.750"	25'	930	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco
5 1/2"	.750"	25'	1045	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco
5 1/2"	.750"	30'	1240	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco

Drill pipe usage notes

1. New drill pipe should be pasted oil before connection
2. Make up and break at least 3 times before drilling
3. Hard bending and plastic coating can be processed according to clients’ special requirements

Our Services

1. Drill pipe strictly in accordance with ISO9001 standard

2. If you find a quality problem within one month of the package being returned.

3. All obligations and responsibilities are strictly performed in accordance with the contract

4. 24-hour online customer service, feel free to contact us.

FAQ

Q: What is your delivery time?
A: It usually takes 20 days to produce. Within 3 days (if there is stock).

Q: How to control the quality?
A: Before shipping, we should check and test each drill rod.

Q: Do you agree to order samples?
A: Yes, we welcome your sample order to test our quality.

Q: Has your drill pipe been heat treated?
A: Yes, our heat treatment of drill pipe and casing.

Q: Does your drill pipe have anti-rust function?
A: Yes, each drill pipe and casing will be anti-rust with paint or anti-corrosion oil before transportation. If you need galvanized pipe, please contact us.
