20FT High Strength E75 Drill Pipe , 4-1/2 Drill Pipe

Large Image : 20FT High Strength E75 Drill Pipe , 4-1/2 Drill Pipe

Product Details:

Place of Origin:	Hebei China
Brand Name:	BaiWei
Certification:	ISO9001
Model Number:	4.5"

Payment & Shipping Terms:

Minimum Order Quantity:	30pcs
Price:	Negotiable
Packaging Details:	According to customer needs
Delivery Time:	20-30 working days, which will be adjusted according to different products and inventory
Payment Terms:	T/T

Contact Now

20FT High Strength E75 Drill Pipe , 4-1/2 Drill Pipe

Description

Type:	Watet Well Drill Pipes	Machine Type:	Drilling Equipment
Material:	High Manganese Steel	Processing Type:	Forging
Use:	Well Drilling	Application:	Well Drilling,DTH Drilling, Coal Drilling, Quarrying
Pressure:	High Pressure	Diameter:	50mm To 159mm
Length:	15FT/20FT/25FT	Color:	Request
Advantage:	High Performance	Usage:	Well Drilling
Highlight:	s135 drill pipe , 20FT s135 drill pipe , S135 4-1/2 drill pipe

High Strength Outer Flat Drill Pipe Round Drill Pipe For Mining Drilling Rig

Product Description

The flat drill pipe is mainly suitable for water hammer rotary drilling (liquid and gas). It has the characteristics of high rigidity, good air tightness, flat external structure, low rotating torque and low resistance. The main specifications include ￠ 50 ￠ 60 ￠ 73 ￠ 89 ￠ 114, which can also be customized as required.

OD A	Wall B	Length L	Weight lbs	ID Pin C	Across Flat D	Flat Length E	Dist From Shoulder F	Flat Length G	Across Flat H	Connection
3.5"	.315"	20'	245	1.75"	2.75"	12.5"	3.25"	2.25"	3.25"	2 3/8IF
4.5"	.337"	20'	345	1.75"	3"	12.5"	3.25"	2.375"	4"	3 1/2 Reg
4 1/2"	.337"	20'	345	2 1/8"	3"	12 1/2"	3 1/4"	2 3/8"	4"	2 7/8 IF
4 1/2"	.337"	25'	430	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.337"	25'	430	2 1/8"	3"	12 1/2"	3 1/4"	2 3/8"	4"	2 7/8 IF
4 1/2"	.337"	30'	510	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.500"	25'	510	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.500"	30'	615	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
4 1/2"	.750"	25'	805	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.500"	25'	695	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.500"	30'	775	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.750"	30'	1100	1 3/4"	3"	12 1/2"	3 1/4"	2 3/8"	4"	3 1/2 Reg
5"	.750"	25'	930	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco
5 1/2"	.750"	25'	1045	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco
5 1/2"	.750"	30'	1240	1 1/2"	3"	12 1/2"	3 1/4"	2 3/8"	4 5/8"	3 1/2 Beco

Drill pipe usage notes

1. New drill pipe should be oiled before connecting
2. Trim and break at least 3 times before drilling
3. Hard bending and plastic coating can be processed according to the special requirements of customers

FAQ

Q: What is your delivery time?
A: It usually takes 20 days to produce. Within 3 days (if there is stock).

Q: How to control the quality?
A: Before shipping, we should check and test each drill rod.

Q: Has your drill pipe been heat treated?
A: Yes, our heat treatment of drill pipe and casing.

Q: Does your drill pipe have anti-rust function?
A: Yes, each drill pipe and casing will be anti-rust with paint or anti-corrosion oil before transportation. If you need galvanized pipe, please contact us.
