E75 G105 S135 Seamless Steel Water Well Drill Pipe For Water Well Drilling
Product Description
The drill pipe is a steel pipe with thread on the tail, which is used to connect the surface equipment of the drilling rig with the drilling equipment or bottom hole device located at the bottom of the drilling well. The purpose of the drill pipe is to transport the drilling mud to the drill bit, and together with the drill bit to raise, lower or rotate the bottom hole device. The drill pipe must be able to withstand huge internal and external pressures, twists, bends and vibrations. During the extraction and refining of oil and gas, the drill pipe can be used multiple times. The drill pipe is divided into three types: square drill pipe, drill pipe and weighted drill pipe. The connection sequence is square drill pipe (1 piece) + drill pipe (n pieces, determined by the well depth) + weighted drill pipe (n pieces, determined by the design of the drill tool combination). The classification of drill pipe, drill pipe joints, drill pipe specifications, and steel grade and strength of drill pipe are introduced in detail.
| Drill pipe diameter (mm) |
Drill pipe length (mm) |
Wall Thickness (mm) |
Type of threads |
Spanner slot (mm) |
| 3 1/2 |
89 |
1000-9144 |
6 |
API 2 3/8"IF |
square 70/64 |
| 4 |
102 |
1000-9144 |
8.38 |
API 2 7/8"IF |
square 76/89 |
| 4 1/2 |
114 |
1500-9144 |
8.38 |
API 3 1/2"REG/IF |
89/95 |
| 5 |
127 |
1500-9144 |
9.19 |
API 3 1/2"REG/IF |
89 |
| 5 1/2 |
140 |
1500-9144 |
10.00-25.4 |
API 4 1/2'REG/IF or 4'FH |
114 |
| 6 1/4 |
168 |
3000-9144 |
10.00-25.4 |
API 4 1/2'REG/IF or 4'FH |
127 |
| 7 |
178 |
3000-9144 |
12.7-25.4 |
5 1/2/FH/REG |
127 |
| 7 5/8 |
194 |
3000-9144 |
12.7-25.4 |
6 5/8/REG |
152 |
Main features
The drill pipe is a steel pipe with a thread at the tail, which is used to connect the surface equipment of the drilling rig and the drilling and grinding equipment or bottom hole device located at the bottom end of the drilling well. The purpose of the drill pipe is to transport the drilling mud to the drill bit, and together with the drill bit to raise, lower or rotate the bottom hole device. The drill pipe must be able to withstand huge internal and external pressures, twists, bends and vibrations. During the extraction and refining of oil and gas, the drill pipe can be used multiple times.
Used in
Our water well drill pipe can be used for water well drilling, geothermal well drilling, pipe shed support drilling and other projects. They are widely used by our domestic and foreign customers. We also provide downhole drill pipes, oil drill pipes and trenchless drill pipes, drilling equipment and some other drilling tools.
FAQ
Q: What's your delivery time?
A: Commonly produce need 20 days to produce. Within 3 days if in stock.
Q: How to control the quality?
A: We should be checking & testing everyone drill rod before shipment.
Q: Do you agree sample order?
A: Yes, we are welcome your sample order to testing our quality.
Q: Does your drill rod have heat treatment?
A: Yes, the heat treatment for our drill rods and casing pipes.
Q: Does your drill rod have rust prevention?
A: Yes, every one drill rod and casing pipe will be with the rust prevention by paint or anticorrosive oil before shipping. If you need galvanized pipes pls contact us the price.
